LED Warning Lights

Continuation from this thread:
LED Turn Signals

[video]http://www.youtube.com/watch?v=16QhlDXbklY[/video]





I probably won't wire in the diodes until I have tested out the turnsignals without them. They are theoretically used as the turnsignals provide the ground for the Turn Signal Indicator and there may not be enough resistance to make it work. But the turnsignals may have resistors to make them work, so I'll have to wait.

In the meantime I will wire in the high beam (main) indicator light. And I can assemble the LED for the turnsignal indicator to at least get somewhat ready.

For a bright H/L indicator I went with a blue, submersible LED for a Live Well (it turns out Fish like blue light!).

Unclviny

Unclviny said:

For a bright H/L indicator I went with a blue, submersible LED for a Live Well (it turns out Fish like blue light!).

Unclviny

Click to expand...

I went with white because I thought a blue or red or green light passing through the lens would cut more light coming through. I might be wrong.

unsure what these turn signals things are used for?? sounds like something for a wheel chair or something -

course might be wrong, web search does suggest most jap bikes do have them :mrgreen:

Yeah, they were never on the 69/70 models, must be an addition or addendum?

Dave
69S

I have one daughter that is sorta quiet like yours and one who really needs a muffler :wink:

Her legs look almost as big as yours, is she going to be the "voice activated starter" :mrgreen:

Jean

Jeandr said:

I have one daughter that is sorta quiet like yours and one who really needs a muffler :wink:

Her legs look almost as big as yours, is she going to be the "voice activated starter" :mrgreen:

Jean

Click to expand...

I think she'll yell, which will startle me into kicking and thus starting the bike. I guess you could call it a remote starter...
