GEARCHANGE INDICATOR

P

pierodn

Joined

Nov 10, 2012

Messages

3,154

• Apr 4, 2013

• #1

Dear All,
i am very happy my transmission goes very well after complete hand made rebuilding but ..... the GEARCHANGE INDICATOR dont moves!!! when i push the pedal.
I cannot understand if i mount it in wrong way, neither i understand if there is another mounting way!.
I hope in your sugestions.
Ciao.
Piero



Hobot

Joined

Oct 19, 2005

Messages

18,978

• Apr 4, 2013

• #2

my rear sets removed my indicator but IIRC the needle ring seats on outer shaft rim with a washer on top so lever bolt compressed it to move with outer shift shaft leaving proud center shaft free to pivot. Definitely helpful item after stops or stalls to know which way to snick for N and a glance down at lights before easing off clutch in N to wait and wait.



DogT

VIP MEMBER

Joined

Jan 20, 2009

Messages

7,394

• Apr 4, 2013

• #3

Indicator (17) moves with bushing (2) not with lever (11), correct??? Spacers must be correct.

http://www.oldbritts.com/1971_g7.html

Dave
69S



P

pierodn

Joined

Nov 10, 2012

Messages

3,154

• Apr 5, 2013

• #4

DogT said:

Indicator (17) moves with bushing (2) not with lever (11), correct??? Spacers must be correct.

http://www.oldbritts.com/1971_g7.html

Dave
69S

Click to expand...

Dear Dave,
is mounted as you say but it does not move.
Ciao.
Piero



R

rpatton

Joined

May 17, 2011

Messages

717

• Apr 5, 2013

• #5

I think it is bolted to the ratchet plate 04-0111 with an emphasis on 'think' :roll: it's been a while.

http://www.oldbritts.com/1973_g8.html



DogT

VIP MEMBER

Joined

Jan 20, 2009

Messages

7,394

• Apr 5, 2013

• #6

Yes, the indicator bolts to the ratchet plate, item 3, and works independent from the lever which is attached to the 'shift pawl carrier', item 10 here. http://www.oldbritts.com/1971_g6.html

It should look like this. Arrow is marking the ratchet plate end.

Dave
69S
