connector location

Status
Not open for further replies.
maylar

maylar

VIP MEMBER
Joined
May 13, 2007
Messages
4,213
Country flag
Three unused wires (Interpol?) NB, NP, GP, on a 74 harness show on the wiring diagram as going between 2 terminal blocks. One I'm sure is in that big block under the tank. Where's the other end?

The white/red one terminates in the connector block under the tank and is hot when the spare button is pressed. I use mine to operate a homemade chain oiler made from a washer fluid pump. You can use it for anything else that you'd like to operate as long as you hold down the button.

ewgoforth said:
The white/red one terminates in the connector block under the tank and is hot when the spare button is pressed. I use mine to operate a homemade chain oiler made from a washer fluid pump. You can use it for anything else that you'd like to operate as long as you hold down the button.
Click to expand...
Mine is being used for the e-starter. The 3 I'm asking about are brown black, brown purple and green purple which were used for Interpol horns and flasher.

I think they exit the harness somewhere around the frame grommet.
I'd have to look again but I think mine are tied off high, towards the front of the battery box.

Matt Spencer said:
They plug into a neuclear reactor in a parrallel universe .
This is why Nortn commandos are so fast .
Click to expand...

Peter R said:
I have removed all unused wires from the stock harness.
Click to expand...

Which is the reason for my query. I want to reduce the bulk of connectors under my tank. Those 3 wires can be tied up with tape and eliminate the bullet sleeves. If the other end is in the battery compartment (thanks @MichaelB) they're already out of the way. Not looking to do major surgery to the harness, just want it a tad neater.

Last edited:
