Who sells best mukini 34mm intake for 850 Commando??

Mark Cigainero · Mar 9, 2011

Is the Aluminum Mikuni 34mm intake manifold (2 into one) that MAP sells a decent manifold?? If not who do you recommend I buy one from???

pelican · Mar 9, 2011

that's the only one I know of.... I wish someone made a nicer one

mikegray660 · Mar 9, 2011

have you tried sudco? of course them and map may get them from the same supplier

geo46er · Mar 9, 2011

Hi Mark,
I can't say for sure that it will fit a Mikuni (VM34mm OD=40mm). Check out www.clubmanracing.com click on fuel delivery/carb kits, scroll down. They have a one into two manifold for the Amal MKII carb and it lists for only $56. Give them a call and ask.

GB

bpatton · Mar 10, 2011

I've had one from each. They are different castings, but they didn't seem to differ much internally.

Carbonfibre · Mar 10, 2011

The best intake manifold for the 34mm Mikuni is available from Allens Performance in the UK, and seems to work quite a bit better than similar looking alternatives.

Hobot · Mar 10, 2011

I was so surprised on extra power of Sudico manifold +34 Miki carb over dual Amals on same set up, but for low down response, but glad to know of a bit better manifold. Here the web site to shop your lead
http://www.allensperformance.co.uk/

geo46er · Mar 10, 2011

Hi again,
If you go on the Allen's performance website and click on their carb kits, in the photo you can practically read MAP right off the manifold, so I guess they are not selling anything different.
Another thing to consider if buying used is bolt hole spread (carb side). I had purchased my manifold (MAP) from Ebay and didn't realize till later that it was drilled with a two inch spread for Amal carbs. Which is OK unless you plan to use it with a Mikuni as I did. It turns out that from Sudco the bolt on rubber spigot mounts for this type of manifold are like $90 which is 4 times as much as the other style. Fortunately I was able to re-drill it without it looking like a bodge-job.

GB

Hobot · Mar 10, 2011

Pretty limited to what can be done with mono carb manifold. Here's what Drouin looks like 40 mm down to dual 32 outlets.

Who sells best mukini 34mm intake for 850 Commando??

mikegray660 · Mar 10, 2011

WTF
little off track logic from a mikuni manifold to a drouin - ahh us boys must show our toys thing eh? (not that i don't think there cool)

Hobot · Mar 10, 2011

Drouin manifold example may be a model that flows better since its cleavage has a clean profile with the fasteners outside. May not be doable for a carb d/t the space for carb to project backwards. Can't see much to improve on off the shelf single carb manifolds, except maybe fill center fastener holes with RTV to streamline.

Carbonfibre · Mar 11, 2011

geo46er said:
Hi again,
If you go on the Allen's performance website and click on their carb kits, in the photo you can practically read MAP right off the manifold, so I guess they are not selling anything different.
Another thing to consider if buying used is bolt hole spread (carb side). I had purchased my manifold (MAP) from Ebay and didn't realize till later that it was drilled with a two inch spread for Amal carbs. Which is OK unless you plan to use it with a Mikuni as I did. It turns out that from Sudco the bolt on rubber spigot mounts for this type of manifold are like $90 which is 4 times as much as the other style. Fortunately I was able to re-drill it without it looking like a bodge-job.

GB

The manifolds being manufactured now are made in the UK, and seem to work quite a bit better than the MAP type sold formerly.

pelican · Mar 11, 2011

I emailed them yesterday to see if they would send a picture of one.

Steve maney makes some nice billet manifolds, but only for double carbs. I asked if he had ever made a 2 into 1, and he said no because he only makes things for race application

Carbonfibre · Mar 11, 2011

I know the guy thats casting them..........the one I saw looked very good indeed!

Who sells best mukini 34mm intake for 850 Commando??
