Rear fender transfers.

Hi
Did the Commando 850 interstate have two rear fender transfers? if so is anyone able to post a photo of the correct position for each of these to be attached.

Thanks for any help with this.

Neil.

According to the AN parts list for '74, one item, part 030517, now part 035073: http://www.nortonmotors.de/ANIL/Norton% ... 027&Part=2 (positioned as shown on the drawing) however, sticker 030517* is the small 5mm x 26mm upper yoke sticker: and not the rear mudguard sticker:
Only 035073 or 064062 are listed in the parts books as being fixed to the rear mudguard** (not including Fastback models).


***Also the Norton factory Mk2/2A parts supplement lists the item as 064062 which is the 'Made in England by Norton Triumph' sticker and I think that would be the correct item for '74-'75.



* ** *** (ZFD - any comments?)

My MK2A no 310410 has the single decal equidistant between the top of the black rear light housing and the rear of the Interstate seat, about an inch from both.

kommando said:

My MK2A no 310410 has the single

decal equidistant between the top of the black rear light housing and the rear of the Interstate seat, about an inch from both.

Click to expand...

My '73 850 Interstate is the same...
