Holey Z Plates!!!

Brooking 850

VIP MEMBER

Joined

Oct 3, 2011

Messages

1,612

• Dec 22, 2012

• #1

Hi all, any chance of some pics of members std C'do Z plates modified for rearsets and full of holes for lightening?
Looking to modify a set for Bike #2 project and could do with some guideline before I fill them full of holes!
Regards Mike



B

bwolfie

Joined

Sep 21, 2010

Messages

3,289

• Dec 22, 2012

• #2

On my alloy bike I ditched them and made these. If you are open to something other than stock.

1\4 aluminum. Stock mufflers could be supported by a cradle mounted mount.



Hobot

Joined

Oct 19, 2005

Messages

18,978

• Dec 22, 2012

• #3

Minus the fold up foot peg d/t trailer travel clearance. Peg stud in Peel's case goes through the rear most factory peg stalk hole, opened up for bigger Harley size bolt.



Brooking 850

VIP MEMBER

Joined

Oct 3, 2011

Messages

1,612

• Dec 22, 2012

• #4

Thanks guys keep them coming
Regards Mike



Hobot

Joined

Oct 19, 2005

Messages

18,978

• Dec 22, 2012

• #5

This is past Ms Peel with John Tinkle aka universal off the shelf rear set style but note the mount plate is not done by instructions or brake cable ends up as crooked as factory but a straight run here, after the brake plate stopper peg hung outside the swing arm slot. Note also I don't like same size air holes where I can get away with variation to match space for more crop circle effect.



A

aboone

Joined

Apr 6, 2012

Messages

35

• Dec 22, 2012

• #6

bwolfie, who made your reverse cones and pipes, very cool!



B

bwolfie

Joined

Sep 21, 2010

Messages

3,289

• Dec 22, 2012

• #7

Hooker TT pipes and Cone Engineering SS mufflers. http://www.coneeng.com/
