exhaust nuts

Status
Not open for further replies.
[quote="searuttps://picasaweb.google.com/lh/photo/x-d7WsXjFl8QjeasOgQo41scGaxh7wFLht_Pd3wmaP0?feat=directlink
What kind of exhaust rose nut I must BUY ???[/quote]

The only thing that matters is the style of PIPE retention. Pull it out and look at it !!!!

There are basically 4 types I am aware of.

original thin flange from 1949 until 1973-750 ... all use .72" of thread whether small fin or 1973 750 only big fin style.

73-74 850 captive collet insert .62" of thread

1975 flared collet .62" of thread

aftermarket unbalanced 750 type... same as 1975 flared collet style use 850 .62" of thread

Based on your pix you need early 750 or 1973 750 big fin

Beach said:
When using the 750 unbalanced pipes with the 850 exhaust nuts, an extra crush washer will take up the space needed for the shorter threads..
Click to expand...

That worked for me too.
I suggest to retighten nuts while engine running 2-3000 rpm.

we were never allowed to tighten anything on alloy heads when they were hot. I still believe in that. I think the solid aluminium washers the best one, especially when using some Maniseal to prevent leaks. I still use the original lack tabs to on my 750. The 80 is another story I have written about.

searunner said:
When I said BAD exhaust rose nuts They are really very BAD -inserted by hammer blows- welded-twisted -
here the photos
https://picasaweb.google.com/lh/photo/M ... directlink
https://picasaweb.google.com/lh/photo/r ... directlink
And when I said RH 10 Head it is really one of the best
https://picasaweb.google.com/lh/photo/R ... directlink
So I suppose my exhaust rose nut must have 30 mm diameter-
hoping to find inside, two good bronze nuts, with correct thread
Click to expand...

CNW has really nice exhaust nuts...
exhaust nuts

That looks nice. I always thought the ones that come with the Maney exhaust system look small and nice.

When using the 750 unbalanced pipes with the 850 exhaust nuts
Click to expand...

I use the 750 unbalanced pipes on my 850, I keep the spherical mount and together with the crush washer you get the adjustability of the balanced pipes and could use the 850 nuts but I use bronze nuts with the long thread.
