Strewth guys, that was a heck of a difficult day. Struggled like mad with the needle settings and other BS. Tried many permutations, summary below. Also had engine / cradle studs fall out due to squashed powder coating (don't get me started on this) and lack of AF spanners on hand meant this kept recurring! Sadly guys, I ran out of time to test the crossover pipes (sorry Sam et al)!
Anyway, here's the headlines...
The initial run was using the same set up as my last visit to the dyno, just to get a baseline from which to compare things against. The list below shows the variance against this baseline:
1. The baseline (as before) = 840cc, stock RH10 head, JS1 cam, 10.5:1 CR, 35mm FCR jetting as supplied but with enriched needle, stock filter adapter stubs on carbs, 1 3/8 pipes, 1 3/8 fluted peashooters.
2. As base plus 70mm long velocity stacks: Power +1.4@ -100rpm. Torque -2.9@ +1600rpm.
3. As base plus 40mm long velocity stacks: Power +1.8@ -100rpm. Torque +0.3@ +1700rpm.
4. As base plus 1 1/2 pipes: Power -5.1@ +200rpm. Torque -0.2@ -200rpm.
5. As above plus 1 clip weaker on needle: Power -5@ +400rpm. Torque -0.1@ same rpm.
6. As 4 + 70mm long velocity stacks: Power -2.2@ +400rpm. Torque -0.8@ -100rpm.
7. As above with anti reversion discs: Power -2.3@ +200rpm. Torque same @ same rpm.
8. As base plus Maney system: Power +4.1@ -100 rpm. Torque +4.3@ +1200rpm.
Summary:
Something is wrong, either with the dyno, or my engine as the baseline was several BHP less than last time with same set up. The dyno man is convinced his dyno is fine, so I may have some engine related issue. But, I decided to continue (the show must go on etc) as the purpose was to compare different permutations, not strive for highest reading.
On all but one permutation the carb needle setting was weak, ie 'off the AF scale' at times. This may require richer needles (I think, I'm new to FCRs) BUT one permutation made this good, so this may be what I pursue (see final summary point). Either way it needs addressing as this is precisely the range one would sit at for prolonged periods on the road, before holing a piston!
1 1/2 pipes did not work well. This surprised me as I thought they felt good when I road tested them. I think this is because they gave a low RPM torque peak and a high RPM power peak, creating a feeling of a broad spread of power, making it feel stronger, when in fact it was not.
Velocity stacks do work well. Both short and long were good, little difference between them, but the short ones are best. They gave smoother readings and better figures.
Anti reversion discs had almost zero effect. This does not argue against anti reversion theory, only that my shoddy attempt was, well, shoddy!
Maney system gave the best results and was the ONLY time the fuelling was OK on the needle. This is one well designed exhaust system. Well, I say best, but I mean 'best for my riding style'. Below 4000rpm, the 1 3/8 system was best. But above 4000rpm the Maney sytem was much better. It gave a much higher average power and torque above 4000. Even from below 4000rpm, although the graphs were less flat, they had a nice linear climb. If I add the increase to my earlier base line readings (pre mystery power loss) the Maney system would put me over 60BHP WITH A STOCK HEAD! The head is now clearly the bottleneck and must be addressed next, and I suspect the Maney system effect may be amplified by head work (and possible cam change). It looks like I need a Maney system (or at least a copy of)!
That's all folks, hope there's something of interest there for some.
