I have recently fitted the belt version.
My 850cc machine was built by Norvil Motorcycles, from spares in 2002 and has a primary belt drive.
Hawkshaw Motorcycles starting advertising it very recently so I took the plunge and ordered one after assurances from Jim Hawkshaw that it would be compatible with a Norvil belt drive.
I stripped out the primary drive and tried to fit the new Alton chaincase. It would not lay flat on the crankcase. The Alton starter motor gearbox on the rear of the chaincase was fouling the crankcase. I ground away a little metal from the crankcase and obtained a good fit. The problem here is that later crankcases are thicker and Alton had not allowed for this. There was worse to come!
I had not touched the gearbox adjustment and simply went to replace the clutch pulley. It would not fit as it was fouling the cast pillar. It would fit if the gearbox was pushed back but then my belt was too short and my rear drive chain was almost hanging on the floor!
Jim Hawkshaw was very helpful and immediately set about resolving the problem. He was hampered by the fact that my problem arose just when Paul at Alton left for a two week holiday. We considered finding a longer belt but this in the end proved too difficult. Because the Norvil 72 tooth clutch pulley is alloy, it is very thick and large in diameter. The total gearbox adjustment range was only about 5mm making specifying a belt length very difficult. The longer term solution to enable this clutch pulley to be used would be to redesign the casting and I understand Alton is considering this.
Whilst all this was going on I did a trial fit of the crankshaft components and found that the starter chain drive would not align. This was largely due to the design of the Norvil crank pulley side plate, which would have required modification.
So Jim at Hawkshaw determined that the only way to get me out of this fix was to supply a new belt drive kit. In co-operation with Tony Hayward, he arranged for Tony to despatch one to me free of charge and it duly arrived in a couple of days.
The Hayward drive uses a 10mm pitch belt as opposed to the Norvil 8mm pitch and although the clutch pulley is anodised alloy, it is much smaller in diameter. Assembly was much easier than before but there were still some minor adjustments to make. To obtain alignment of the crank and clutch pulleys I needed to grind the clutch circlip spacer down by about 1.5mm. I had re-used the original clutch centre so whether this was due to a peculiarity of the Norvil item, I can’t say. Also, the starter chain was out of alignment by a similar amount and the back face of the large spacer between the crank pulley and the sprag required grinding down.
Apart from a bit of easing of crankshaft keyways, everything else went together perfectly. Once the assembly was complete minus the alternator, I was able to run the starter with the engine spark plugs removed and check that the belt ran true. Setting the rotor gap on the alternator is a doddle using the supplied shims. On the electrical side, the bracket supplied for the starter relay is designed to fit on top of a YTX-20L-BS battery but I preferred to fit a Shorai LFX18 Li-ion type to save space and weight. The extra space in the battery compartment allowed me to bolt down the relay and also fit my Scotoiler reservoir.
Starting on the button is instant! I can't tell you how thrilled I am to have a bike I can just get on and ride without busting my knee!
In summary, the Alton kit will fit a belt drive bike but not all of them. They have some more work to do to make it truly universal but I think we have to appreciate the enormity of the task and accept that some customisation may be necessary. I have only the highest praise for Jim Hawkshaw for generously doing his utmost to ensure I got the end result I wanted and also for Tony Hayward for helping out and giving advice on the phone.
