850 Clutch disc identification

MexicoMike

Joined

Jan 31, 2010

Messages

3,025

• Mar 2, 2010

• #1

I've been reading descriptions of the Commando clutch and I'm not sure if what I have is oem or something else.

This is a friction disc and the pressure plate but all the steel plates look exactly like the finish on the pressure plate.



L.A.B.

Moderator

VIP MEMBER

Joined

Nov 20, 2004

Messages

20,102

• Mar 2, 2010

• #2

MexicoMike said:

I've been reading descriptions of the Commando clutch and I'm not sure if what I have is oem or something else.

Click to expand...

It would be more likely that your 850 had the 'five bronze friction plate' clutch originally, I think? http://www.oldbritts.com/ob_clutch_info.html



swooshdave

Joined

Apr 15, 2009

Messages

11,520

• Mar 2, 2010

• #3

Isn't that a Barnett friction disk?



maylar

VIP MEMBER

Joined

May 13, 2007

Messages

4,213

• Mar 3, 2010

• #4

The 850 used 5 sintered bronze plates .125 inch thick with a thin pressure plate. The 750 had 4 fiber plates about .145 thick and a thicker pressure plate. If you have 5 of those in your 850 they're aftermarket.
