Öhlins FG 333 Front Fork Spare Parts List for Norton Commando 961
Download the complete PDF version using the green download button at the top right of this page for the Öhlins FG 333 spare parts list covering front forks fitted to Norton Commando models. This factory Öhlins reference provides exploded component diagrams, part numbers and replacement parts information for the complete FG 333 fork assembly.
The parts list includes the full fork assembly breakdown with numbered references for the top cap, adjusters, preload tube, spring support, fork spring, seal head, bushings, rebound and compression components, inner tube assembly, outer tube, fork bottoms, O-rings, circlips, washers, oil seal and scraper.
Spring options are also listed, including the standard 8.5 N/mm spring together with optional 8.0, 9.0, 9.5 and 10.0 N/mm alternatives. This is a useful reference for Norton Commando owners, restorers and suspension rebuilders servicing Öhlins FG 333 front forks.
Contents Include
- Öhlins FG 333 spare parts list
- Front fork application for Norton Commando
- Exploded fork assembly diagram
- Top cap, adjuster and preload tube parts
- Fork spring and spring support references
- Seal head, bushings, oil seal and scraper listings
- Inner tube and outer tube component references
- Compression and rebound needle parts
- Fork bottom left and right part numbers
- Standard and optional fork spring rate listings
- O-ring, circlip, washer and fastener references
