How do you fit isolastic rubbers?

Status
Not open for further replies.
Joined
Sep 15, 2010
Messages
2
Hi, I am installing new isolastics - verier adjustable type - into the front cradle. The new outer rubbers are the same diameter as the tube and seem to need an awful lot of force, even when using lots oil as a lubricant, to get them inserted. I am concerned that the use of screwdrivers as levers could rip the rubbers or too much force could even tear the rubbers from the shaft. Is there a technique or piece of equipment I should be using to make this job easier? Thanks in anticipation. Trev.

Joined
May 2, 2009
Messages
1,390
mine were the same. I worked the edge of the first one in with a screwdriver, sprayed them with silicon grease, and beat it in with a rubber mallet. Maybe someone else knows an easier way, but being wider than the tube it's probably going to be a pain.


maylar

VIP MEMBER
Joined
May 13, 2007
Messages
4,198
Country flag
Had the same issue with mine. Grease, pry, smack with a mallet, swear. I think I ended up squeezing them in with a vice.

Joined
Jun 17, 2009
Messages
642
Please do NOT use oil or grease or any petro based lube.

Clean all that off the rubbers and off the inside of the cradle real good.

Petro based lubes cause the rubber to deteriorate and break down.



Get some Silicone spray lubricant at any auto parts store, use it on the rubbers and inside of cradle, won't harm the rubbers. Use it liberally.


DogT

VIP MEMBER
Joined
Jan 20, 2009
Messages
7,446
Country flag
I just pressed mine in with an appropriate socket. Didn't have to use a hammer or press. Lubed everything up real good with silicone grease. Maybe the early models had softer rubber, I have heard that?

Dave
69S

Joined
Dec 10, 2008
Messages
7,253
Country flag
You really should use rubber lube for this task. Grease or even silicone breaks down the rubber. You can get rubber lube from people who sell tire mounting supplies.
Here is my favorite product.

http://www.ipcol.com/shopexd.asp?id=31

It makes installation a breeze. Jim

Joined
Oct 31, 2009
Messages
5,193
Country flag
Plumbers grease worked great for me. Absolutely non corrosive to rubber.

Turn this little gizmo up on my Smithy. Tapered with lip, driver and stop.
How do you fit isolastic rubbers?


I changed out the front this summer when I noticing it drop off center with the DT type head steady. No vertical support. Also put the stock steady back on for much better overall handling. Also homemade.
How do you fit isolastic rubbers?

Joined
Oct 19, 2005
Messages
18,978
Country flag
Nowadays I just spray with sillycon then pound in with socket of appropriate tube and don't be gentle. It may surprise you how easy they suddenly sink in and calibrates the rest of your taps to center. I don't recommend pounding on the center tube as may tend to separate adhesion and mare the threads. Prior I've fiddled em in by fingers and pry tools. The soonest smoothest Commando I've ever ridden was Peel, whose front doughnuts I trimmed edges so only half width rim remained to contact iso mount. I stuffed extra full width doughnuts in rear to delay the inevitable sag factor.

Always wondered - if/why the small OD donuts are needed. I've never seen evidence that they are ever contacted, even from wheelie or leap landing impacts and various crashes and impacts.

Joined
Feb 3, 2010
Messages
438
Country flag
Seeley920 said:
KY Jelly, then tney should "slip in" with the greatest of ease :lol: :lol: :roll:
:lol: :lol: :lol:
I'm with Seeley and Hobot.
Get bit good and lubed up and it should go in :lol: Sometimes it just slips in, other times you got to work on it :lol:

Joined
Dec 10, 2008
Messages
7,253
Country flag
pvisseriii said:
Plumbers grease worked great for me. Absolutely non corrosive to rubber.

Plumbers grease works without damage to the rubber but it stays around a long time. You really want the lube to go away so the rubber sticks to the metal . This makes the rubber last longer.
Norton used to suggest using gasoline. It make the rubber slippery but evaporated quickly enough that it did little damage to the rubber and left no residue. Not a very safe suggestion.
By the way if you go to the p80 site above you can click on the free sample link and get a small bottle for free. Enough to do a lifetime worth of isolastics. Jim

Joined
Oct 31, 2009
Messages
5,193
Country flag
comnoz said:
pvisseriii said:
Plumbers grease worked great for me. Absolutely non corrosive to rubber.

Plumbers grease works without damage to the rubber but it stays around a long time. You really want the lube to go away so the rubber sticks to the metal . This makes the rubber last longer.
Norton used to suggest using gasoline. It make the rubber slippery but evaporated quickly enough that it did little damage to the rubber and left no residue. Not a very safe suggestion.
By the way if you go to the p80 site above you can click on the free sample link and get a small bottle for free. Enough to do a lifetime worth of isolastics. Jim

That's a good point Jim. I will check that out this winter during my crankcase swap out.

Joined
Apr 15, 2009
Messages
11,415
Country flag
comnoz said:
Norton used to suggest using gasoline. It make the rubber slippery but evaporated quickly enough that it did little damage to the rubber and left no residue. Not a very safe suggestion.

Maybe when gas didn't have all the crap in it as it does now.

Joined
May 2, 2009
Messages
1,390
kinda off topic, but I just saw a commercial on tv today for ethanol. It was a propaganda piece saying ethanol has never started a war, etc...blah, blah, blah. Anyway it was an ad saying we should up the ethanol content of our gas :cry:

Joined
Dec 10, 2008
Messages
7,253
Country flag
Got my free samples of P80 today. Once you have used it to mount a tire or put in some isolastics you will want to keep it around forever. Jim

How do you fit isolastic rubbers?

Joined
Oct 19, 2005
Messages
18,978
Country flag
I've done front iso 3x's in last couple weeks, slowly creeping up on milling mount down till a one man task to fit in frame and still be able to turn the adjuster.

I have been using a Teflon power in fast evap carrier, then put a wood drift on the center tube and use a 3# sludge with one strong BAP to dive it most the way in one swing then fine tune with more lesser Raps. Work the first rubber in rim with down pressure and blunt probe to assist. I used same dry Teflon lube on the sliding washers too. I see how much grit grease collects so also fit the booties.

I had such nice smoothness on trimming Peel's iso rim on bench grinder to about 1/2 thick edge, did the same with Trixie to see if she also likes it that way.
Very little is mentioned in manual about big hammers and wood pieces, but can hardly do much w/o em.
