Fuse box?

Guys,

I'm at the stage of installing a custom wiring harness . The electrical system will be a negative ground. My question is; Is a fuse box a good idea?

I have all modern electrics, no zener diodes, rectum-fryers, etc.

12 volt, marine grade wire and connectors. All new turn signals, horn, batt, light, ignition, etc.


Opinions?

* new voltage reg:

I got one of these. I have hooked everything up on the bench, it's great. So good I might get 1 or 2 more in the future. They can be had shipped for $310.00

It's all digital, features activated by a ground signal, so smaller wires etc...

http://motogadget.com/elektrik/elektron ... erung.html

Hi Skyguyz,

This is the perfect time to install a fuse block into your harness. I installed a 4-fuse block when I converted my Mk3 to negative ground this past year. Summit Racing, among others, have a cheap, small, sealed (o-ring) 4-fuse block using modern blade fuses that is easy to place near the battery. The idea is to isolate the ignition circuit from the horn and lights circuits, allowing for a graceful exit from the road if these circuits fail. I used the extra fuse for the charging circuit.

Saw a guy who went negative ground on his norton and used one from fuzeblocks.com. About $90 and can hold a relay, nice setup

I have a spare eastern beaver setup for sale that i'm not going to use.

Sky,
I like the idea of using a relay to power the ignition, especially if you have a kill switch. Even if you eliminate most of the connections with a custom harness you can have phantom voltage problems from the ignition and basically exposed kill switch contacts. +1 on separate fusing the circuits. Make sure you get the fuses rated correctly.

post125727.html#p125727

bwolfie said:

I got one of these. ....

Click to expand...

Here's the link in english, it's pretty hidden. Under downloads you should find the english manual but it's not there at the moment. I got mine with a printed english manual however.

The interesting bit is also that it has internal fuses. However there is some kind of blow-off capacitor or something like this to indicate abuse like overvoltage (IIRC 18V) or reversed connectors etc - if that lets go the warranty is void.



Tim
