crankshaft radius
- Thread starter John leathers
- Start date
- Status
Fast Eddie
VIP MEMBER
- Joined
- Oct 4, 2013
- Messages
- 20,656
Matchless said:
Good point. I don't know, I've only ever stroked a triple in this way!
Any of our resident Norton experts know?
- Joined
- Aug 26, 2010
- Messages
- 8,215
One of the auto modifiers websites commented that FAA inspectors would be horrified by what goes on in the auto world. !
I'd comment that I sighted recently a neat multicylinder US made bike crank that had been reclaimed by hardchroming ALL the journals,
so we will watch with interest how it goes. Operator apparently had no doubts...
I'd comment that I sighted recently a neat multicylinder US made bike crank that had been reclaimed by hardchroming ALL the journals,
so we will watch with interest how it goes. Operator apparently had no doubts...
comnoz said:
Nater_Potater
VIP MEMBER
- Joined
- Apr 7, 2013
- Messages
- 1,342
It's time...
I'd say "Go buy a new crank, have it checked for cracks (by some other than the last shop), then send that same shop the bill." Of course, if you were to do this, what would we have to talk about?
I'd say "Go buy a new crank, have it checked for cracks (by some other than the last shop), then send that same shop the bill." Of course, if you were to do this, what would we have to talk about?
- Joined
- Dec 10, 2008
- Messages
- 7,253
Fast Eddie said:
The engine in my EFI bike has a stock crank that has been offset ground up to 91mm stroke. It is not welded -just ground undersize by .100 . Then I put a bar through the center of the big ends and bolted it through the cheeks to hopefully keep it together. Jim
Brooking 850
VIP MEMBER
- Joined
- Oct 3, 2011
- Messages
- 1,609
To get your crank back to being useable, here is an idea that was given to me by a Norton engine builder here in NZ after I broke the drive side stub off at the 'pork chop' in my race bike last year.
Set the crank up in a CNC station, centre off the crank on both sides , drive and timing,to set a datum .
Do this with the crank bolted together, in my case it was done centreing off the timing side shaft.
Drill out the offending broken bit (in my case) drill it all the way through the pork chop, lathe up an identical part to the drive or timing side stub, press the new part all the way through the pork chop and TIG weld new the stub on the inside of the pork chop closest to the counterweight
Grind new part to suit main bearing. Balance completed item to suit.
You now have no need for a radius at the pork chop /stub interface , as the stub is now a shaft all the way through.
This was for the main shafts, reread your post and now see it is on the big ends!
Food for thought
Not sure this would be ideal for a race motor, certainly a great fix for road bike.
Regards Mike
Set the crank up in a CNC station, centre off the crank on both sides , drive and timing,to set a datum .
Do this with the crank bolted together, in my case it was done centreing off the timing side shaft.
Drill out the offending broken bit (in my case) drill it all the way through the pork chop, lathe up an identical part to the drive or timing side stub, press the new part all the way through the pork chop and TIG weld new the stub on the inside of the pork chop closest to the counterweight
Grind new part to suit main bearing. Balance completed item to suit.
You now have no need for a radius at the pork chop /stub interface , as the stub is now a shaft all the way through.
This was for the main shafts, reread your post and now see it is on the big ends!
Food for thought
Not sure this would be ideal for a race motor, certainly a great fix for road bike.
Regards Mike
