J Josh Cox Joined Sep 24, 2010 Messages 530 Oct 29, 2010 #1 CAM thrust washer ?, is this washer suposed to be on the TS of the CAM, if so, which way around is it to be installed ?.
CAM thrust washer ?, is this washer suposed to be on the TS of the CAM, if so, which way around is it to be installed ?.
comnoz Joined Dec 10, 2008 Messages 7,253 Oct 29, 2010 #2 Tapered side towards the tack drive gear. Jim
DogT VIP MEMBER Joined Jan 20, 2009 Messages 7,394 Oct 29, 2010 #3 Does this help? Don't get it wrong or you won't get the cases back together as I remember. Dave 69S
L.A.B. Moderator VIP MEMBER Joined Nov 20, 2004 Messages 20,416 Oct 29, 2010 #4 http://britmoto.com/manuals/Manuals/750_man.pdf Section C29, 2
