- Joined
- Apr 15, 2009
- Messages
- 11,520
andrew hester said:You should get the Maney Race exhaust http://www.stevemaney.com/products.html
He wants to show off that there's no battery or oil tank. The Maney exhaust would block that view.
Café Commando build thread
- Thread starter Jeandr
- Start date
He wants to show off that there's no battery or oil tank. The Maney exhaust would block that view.
- Joined
- Jan 22, 2008
- Messages
- 2,585
swooshdave said:andrew hester said:You should get the Maney Race exhaust http://www.stevemaney.com/products.html
He wants to show off that there's no battery or oil tank. The Maney exhaust would block that view.
Not only that, it would add about $1000 + shipping to what I have put into the bike and I could not run it on the street.
Jean
- Joined
- Jan 22, 2008
- Messages
- 2,585
Worked like a dog the last few days, well not quite, I did take time to watch the tour de France, anyway, I did the electrics and the plumbing and put in fluids and made sure all bolts were tight. I adjusted the timing roughly.
Pondered a while until I cam up with this kludge to hold the magnet for the speedo
These are my indicator lights, the orange one is for the... what else orange flashers and the blue one is the high beam indicator.
BTW, the Acewell gauge has some nice features like highest RPM reached and a voltmeter, not to mention two trip meters, highest speed attained. It has a temperature probe, but I didn't put it on, one day I will find a place to mount the probe and hook it up, oil temp would be a nice addition.
Left side
Right side
After getting some gas in the tank, I opened the taps and let the gas fill the carbs. I turned it on and gave one kick and got a little puff, two more kicks got it running. I am very impressed with these carbs, after a bit of warm up, I pushed the enrichers off and let it idle to see the oil coming back, it took quite a bit of time before oil started coming back out of the engine and more so for the oil to exit the filter. Took it up and down the street a few times to check everything. The front brake is so far great, the back one no so much. The shift linkages work , but with all the belcranks and shafts, there is some slop. The front fork is very supple, I have no air in it right now, only the springs. As a test I put in some air and checked a few times and they held up. I think I have 25 PSI in the back shocks.
Later on I will get a proper paint job, now it is time to get it inspected and licensed.
Jean
Pondered a while until I cam up with this kludge to hold the magnet for the speedo
These are my indicator lights, the orange one is for the... what else orange flashers and the blue one is the high beam indicator.
BTW, the Acewell gauge has some nice features like highest RPM reached and a voltmeter, not to mention two trip meters, highest speed attained. It has a temperature probe, but I didn't put it on, one day I will find a place to mount the probe and hook it up, oil temp would be a nice addition.
Left side
Right side
After getting some gas in the tank, I opened the taps and let the gas fill the carbs. I turned it on and gave one kick and got a little puff, two more kicks got it running. I am very impressed with these carbs, after a bit of warm up, I pushed the enrichers off and let it idle to see the oil coming back, it took quite a bit of time before oil started coming back out of the engine and more so for the oil to exit the filter. Took it up and down the street a few times to check everything. The front brake is so far great, the back one no so much. The shift linkages work , but with all the belcranks and shafts, there is some slop. The front fork is very supple, I have no air in it right now, only the springs. As a test I put in some air and checked a few times and they held up. I think I have 25 PSI in the back shocks.
Later on I will get a proper paint job, now it is time to get it inspected and licensed.
Jean
- Joined
- Nov 16, 2010
- Messages
- 1,275
Wonder where the oil cooler is?
- Joined
- Feb 3, 2010
- Messages
- 438
Slap on flashers and taillight from your RD for the inspection, Canadian Tire has some stick-on reflectors that I use for inspection. Once they give you the sticker you can go home and put it back to the way you want it.
The only place I ever had trouble from the cops about lights was in Longueuil.
The only place I ever had trouble from the cops about lights was in Longueuil.
- Joined
- Apr 15, 2009
- Messages
- 11,520
Jeandr said:
I know you're busy but I'd love to see how you made those.
- Joined
- Jan 22, 2008
- Messages
- 2,585
swooshdave said:
The circuit is very simple, the resistor going to the blue LED is connected to the high beam and the other two resistors go to each side of the flashers. The circuit is for NEGATIVE ground, for positive ground, just reverse the LEDs. I built it on a small piece of circuit board and cut the traces with a dremel. I drilled two little holes (1/8") for these LEDs and glued the circuit in place with silicone.
Jean
- Joined
- Jan 22, 2008
- Messages
- 2,585
grandpaul said:
There is no way to keep colors in check with the electrical components coming from many different sources. The only way would be to unsolder and replace the wires in the switches and lights. My wiring is very simple and a lot easier to follow than a stock wiring loom, even accounting for the color changes.
Jean
- Joined
- Jan 12, 2011
- Messages
- 1,723
Interesting, I take it Canada requires flashers be put on bikes even though that was not the law when they were first imported and sold back in the 70s?
Here in the US, maybe I am wrong, but we don't require such "upgrades".
Whatever the law was when sold here stays the same.
Or maybe because I have never had to get a new license (other than annual renewals), I don't have to comply with turn signals and large rear tali light? Mine is a 73 and was sold then with flashers and large light, but I reverted back to the 71 style light and took the flashers off decades ago.
Here in the US, maybe I am wrong, but we don't require such "upgrades".
Whatever the law was when sold here stays the same.
Or maybe because I have never had to get a new license (other than annual renewals), I don't have to comply with turn signals and large rear tali light? Mine is a 73 and was sold then with flashers and large light, but I reverted back to the 71 style light and took the flashers off decades ago.
- Joined
- Jan 22, 2008
- Messages
- 2,585
1up3down said:
I will have it done in red, everything that is now white will be that color. As for the flashers, the bike must have them if they were on when new so a 1969 would not need any, but a 1974 would, then there was the rules which had specifics such as a minimum of 3½ square inches for the flashers, amber in color, clear will not work. The rear lens needs to be red, not clear...
Jean
- Joined
- May 17, 2011
- Messages
- 717
Jeandr said:
Antoine would approve. It reminds me of what a chef told me about the definition of Elegance. 'Simple design with the best ingredients'.
Perfection is achieved, not when there is nothing more to add, but when there is nothing left to take away.
Antoine de Saint-Exupery
- Joined
- Oct 19, 2005
- Messages
- 18,978
Remarkably the most see through road going Cdo I've seen so far, Impressive to view and savor the sensation, thanx. Got a total weight yet? Peel's got special needs so more cluttered when set up with full accessories but will run fine w/o them, just not full potential. Hope you have wiring chart to keep next owner sane.
