Discussion in 'Norton Motorcycle Rebuilds' started by 850commando, Nov 6, 2017.

  1. Fast Eddie

    Fast Eddie VIP MEMBER

    Joined:
    Oct 4, 2013
    Back off and re-torque, one by one, in normal order of sequence.

  2. 850commando

    850commando

    Joined:
    Nov 1, 2014
    [​IMG]
    basket case as it arrived

    [​IMG]

    Last edited: Sep 12, 2018
  3. 850commando

    850commando

    Joined:
    Nov 1, 2014
    finished bike
    [​IMG] [​IMG]
    [​IMG]

    Last edited: Sep 12, 2018
  4. 850commando

    850commando

    Joined:
    Nov 1, 2014
    the following is a list of work carried out.

    Matching serial number bike. frame-up rebuild completed as follows:

    Engine; barrel bored 0.040” over size, new pistons, rings, connecting rod big end brgs replaced, Jim Comstock modified crankcase for CNW reed valve breather (PCV), new Web 312 street cam and new bushings, grade 8 fasteners as required. ARP fasteners on barrel.

    Cylinder head; new kibblewhite valves, valve springs and bronze guides, mushroom head adjusters, Jim Comstock modified 3 head studs and new exhaust port threads, Head planned 0.008”. CNW supplied ARP stainless fasteners for cylinder head

    Gearbox; new bearings, orings, seals and shifter springs

    Isolastic; all new isolastic rubbers, Mick Hemmings isolastic Vernier adjusters, new boots.

    Frame; stripped, sandblasted, epoxy primer and repainted black. Side stand repaired, mainstand welded with new mounting bushings.

    Swingarm; new swingarm shaft, Heinz Kegler modified cradle.

    Suspension; new front fork tubes, and seals, new gaiter boots. Rear shocks new

    Primary drive; new seals and bearing.

    Final drive; new chain and 21t countershaft sprocket.

    Front brake; master cylinder cleaned new seals and rebuilt, brake caliper cleaned new seals and rebuilt. Brake rotor surface cleaned

    Rear brake; cleaned, replace bearing, and oil seals

    Wheels; front wheel new bearings, rear wheel new bearings and bushings, spokes nipples and new 18”rim, replace speedo drive.

    Electrical; boyer brandsen ignition, new custom wiring harness (TXL wire) Neg Gnd c/w fuse panel, h4 headlight and new headlite switch, new ignition switch, shindengen R/R, battery. all LED bulbs except h4.

    Carburation; mikuni 34mm single conversion. New cable.

    Fuel tank; cleaned and rust removed, new fuel taps, new rear mounting strap, original colour red, currently black,

    Seat & side covers; new seat cover. Interstate side covers currently chromed.

    Exhaust; mk3 balanced pipes, new collets and seating washers, nearly new mufflers. New mounting brackets as needed.

    Tires; front 19” tt100, rear 18” shinko 712

    Last edited: Sep 17, 2018
  5. grandpaul

    grandpaul VIP MEMBER

    Joined:
    Jan 15, 2008
    Am I the only one that just sees white screen with a grey icon in the middle, instead of two photos, just above?

  6. alan hodge

    alan hodge VIP MEMBER

    Joined:
    Oct 10, 2017
    i dontsee nuthin neither

  7. Tornado

    Tornado VIP MEMBER

    Joined:
    Dec 5, 2017
    OP stated he closed his image hosting account...so any pics from there will no longer display.
    If he still needs another hosting site, I'd suggest getting VIP membership on this site or try PBASE.COM which I've used since 2001... never had any issues with it.

  8. 850commando

    850commando

    Joined:
    Nov 1, 2014
    well it looks like google photos doesn't want to play nice with the image loading feature here, the pictures were there.

    sorry have to do some digging

  9. grandpaul

    grandpaul VIP MEMBER

    Joined:
    Jan 15, 2008
    A couple (not all) of the photos are showing now (for me, anyway)

    Very nice job!

  10. 850commando

    850commando

    Joined:
    Nov 1, 2014
    It seems i can't go back and edit the early posts to replace the missing pictures, so have settled to just show a before and after.

    Tornado likes this.
