where do you mount your Boyer?

Status
Not open for further replies.
Joined
Dec 2, 2009
Messages
65
Boyer Electronic Ignition that is.
Bike is 1975, I'd sure like a picture of where you put it and how it is connected to the frame. My bike was purchased as a work in progress. PO had basically just zip tied it right behind the coil mount as a temporary mounting while wiring. I moved it so I could install the head steady piece that holds the spring that attaches to the main headsteady part on the head. Also does it need to have some sort of shock proofing? Like a piece of rubber inner tube wraped around it?
Thanks! Its been fun so far! The bike is somewhere in the 75% complete area, however I am back tracking to be sure the prior work was complete. I'm just not taking anything for granted. So far most everything has been first rate. My main items to finish are the wiring, stripped down to just a couple of wires, no signals or handlebar switches, idiot lights or any of the 1975 console lights, there is no console, the PO did it this way, I'm just leaving for now. then some re-constructive work on the rear brakes, there isn't one(!) and a few more odds and ends. then I will be ready to start the never before started brand new rebuilt engine, can hardy wait for that day!!! :D
Kurt

Joined
Jan 31, 2010
Messages
2,926
Country flag
Well, I mounted the Boyer (from previous owner) in a trash can! ;) However, he had it zip-tied to the underside of the top tube with a foam pad between it and the tube and it had been there for some years and around 20k miles. I have seen mounting brackets/plates for them; I think Old Britts sells one.

Joined
Feb 20, 2008
Messages
114
Wrap it in rubber, and leave it loose in the obvious position never had any problems many miles many years.

cheers


L.A.B.

Moderator
VIP MEMBER
Joined
Nov 20, 2004
Messages
18,489
Country flag
When my MkIII had a Boyer*, it was fitted to the underside of the coil bracket between the coils where the ballast resistor and 2CP condenser pack would normally be fitted. I don't believe the Boyer box needs to be rubber mounted, but I always like to isolate a box with a piece foam rubber.

*(My MkIII now has a Tri-Spark Classic Twin ignition, so there's no box)

Joined
May 2, 2009
Messages
1,390
mine was ziptied to the frame in the triangle where the brace meets the backbone...the tank keeps it dry

Joined
Nov 5, 2006
Messages
1,152
Country flag
I also cut open a beer cozy/cooler foam thing and wrapped the box in it before zip tieing it to the top tube - a little shock absorption never hurts!


Ron L

VIP MEMBER
Joined
Feb 27, 2004
Messages
3,122
Country flag
I also cut open a beer cozy/cooler foam thing and wrapped the box in it before zip tieing it to the top tube - a little shock absorption never hurts!

A section of foam pipe insulation works great too. And then you don't have to drink your beer warm! :lol:

Joined
Dec 2, 2009
Messages
65
L.A.B. said:
When my MkIII had a Boyer*, it was fitted to the underside of the coil bracket between the coils where the ballast resistor and 2CP condenser pack would normally be fitted. I don't believe the Boyer box needs to be rubber mounted, but I always like to isolate a box with a piece foam rubber.

*(My MkIII now has a Tri-Spark Classic Twin ignition, so there's no box)

I like that spot.
Thanks!


maylar

VIP MEMBER
Joined
May 13, 2007
Messages
4,198
Country flag
pelican said:
mine was ziptied to the frame in the triangle where the brace meets the backbone...the tank keeps it dry
That's where mine was for 25 years too.

Joined
Aug 14, 2006
Messages
1,451
Country flag
Originally mine was stuck to the front/top area of the battery tray area, where the old airfilter box was. Previous owner glued the Boyer box toa piece of foam rubebr, then that was glued to the top of the battery tray. It was ugly for sure.

Now that I've moved on to a Tri-Spark I don't heave to deal with a little black box any longer.


grandpaul

VIP MEMBER
Joined
Jan 15, 2008
Messages
12,456
Country flag
I wouldn't wrap the blax box fully, it needs ambient cooling.

The hollow area inside the coil mount is a good location to allow good cooling airflow.

Joined
Dec 2, 2009
Messages
65
grandpaul said:
I wouldn't wrap the blax box fully, it needs ambient cooling.

The hollow area inside the coil mount is a good location to allow good cooling airflow.

Would you wrap it or put a piece of inner tube on one side? I figure if I just wrap in but still leave the front open some air will pass. Enough? I'm also wondering about vibration.


batrider

VIP MEMBER
Joined
Aug 9, 2008
Messages
2,293
Country flag
I unpotted my Boyer box of black plasticky goo and there really is nothing in there to vibrate as long as the potting material is present. The stuff is like the old "Turkish Taffy" but black. I wrapped mine a couple wraps in an old inner tube with the front and back open and put it under the main tube with a big ty-wrap and it is still that way. It is the potting shell you need to protect from vibration. It is brittle and thin and mine had a small piece missing from the side but it won't affect operation. Maybe some big stick-on rubber feet top and bottom would allow you to wedge it in there for better cooling.

Heat rising up from my engine while idling in traffic on a hot day made my early 1974 Boyer leak out a bit of goo so that's why I eventually re-did it (way too much work but it was fun). I refilled it with some modern 2-part hi tech flexible stuff that we use at work for potting high voltage modules. The new potting material is a reddish orange in color. Somewhere I read that Boyer is also using an improved material now.


Flo

Joined
Aug 4, 2009
Messages
777
where do you mount your Boyer?

O/k, it is filthy. Working on it now. Bloody wiring!

Joined
Jan 27, 2008
Messages
1,607
Country flag
kwb210 said:
L.A.B. said:
When my MkIII had a Boyer*, it was fitted to the underside of the coil bracket between the coils where the ballast resistor and 2CP condenser pack would normally be fitted. I don't believe the Boyer box needs to be rubber mounted, but I always like to isolate a box with a piece foam rubber.

*(My MkIII now has a Tri-Spark Classic Twin ignition, so there's no box)

I like that spot.
Thanks!
I mounted mine there, too. Since the condenser and ballast resistor are gone, it fits nicely in there. A little Velcro on one side (I mounted it vertically) and a zip-tie through the old condenser mounting holes - done!

Joined
Apr 15, 2009
Messages
11,415
Country flag
Keith1069 said:
Not a Boyer though........
where do you mount your Boyer?

where do you mount your Boyer?


If you've never cruised through Keith Photobucket Album, you should. Very fascinating. And I so want to make a headsteady just like his.
