Top Fork Bolts Removal and Installation

askdoctorday · Apr 19, 2013

Howdy- Two questions regarding installation/removal of the top fork bolts: 1) I've been using a set of plumber's bells to remove/install the fork bolts. Has anyone found a source for the proper size socket for this? It measures about 33.34 mm and I haven't been able to run one down. 2) Is there a specific torque value for tightening them, or is it just a snug 'em up tight kind of thing?

Any and all advice much appreciated as always.

Eric

john robert bould · Apr 19, 2013

I have lots of plate spanners , you can have one for postage costs,,you can view them on this forum some where.

Mike Sullivan · Apr 19, 2013

I got a socket to fit from Allwoods the Motor Factors (1/2" drive). John's sockets are also fine - I have one that was supplied with his excellent damper kit!

The MK III Workshop Manual indicates 30ftlbs for part #06-0345 (stanchion top chrome nuts), I just do mine up 'tight' ;-)

Mike

MKIII Commando

L.A.B. · Apr 19, 2013

askdoctorday said:
33.34 mm

= 1-5/16"

pete.v · Apr 19, 2013

A 34mm works just fine.

kevbo82 · Apr 19, 2013

i found an 1 5/16" socket at ace hardware, it was 3/4" drive so i had to use an adaptor at home. my dad also had a great little wrench in his norton tools, it's a really flat 9/16" ,right angle on one end (perfect for fitting in and getting those fork nuts off) and the straight end is a perfect fit inside the chain guard to undue the shock nut.

concours · Apr 19, 2013

A 1-5/16" six point socket is a good fit. Be sure to grind the chamfer off the socket so it grips the shallow nut well.
I have one of these as well: http://www.mscdirect.com/product/81727190

askdoctorday · Apr 21, 2013

Thanks everyone- I found a 1 5/16 socket, torqued it as specified. Thanks for all the help, as always.
