Need fork tube measurement

I need a few measurements of various Nort fork tubes at the bottom where the lower bush slips on so I can get an average to make sure my Turcite bushings are sized correctly. Much appreciated.

Jim

You're talking this?



I get 1.287 on my original APR69 S forks.

The bushes I put on my new tubes, I had to Emory down a bit to get them to slide right. I may have even used my originals instead of the replacements I got, can't remember.

Dave
69S

32.44 on one and 32.49 on another.
I am affraid these will vairy from one suppler to another , i have made plastic bushs,and gues what? they are either slack or to tight when the customer trys to fit them,
as you can see from the two sizes i have measured...the only way to get them right is to size each one and custom fit it to the slider. even the top bush can be tricky.

My specs use 1.280 for the ID of the lower bush.

This fits John Robert Boulds specs of 1.277 to 1.279 (32.44mm on one and 32.49mm on another)
