Leaky fuel taps

Status
Not open for further replies.
Joined
Oct 1, 2007
Messages
122
Hi everyone.

Does anyone please have a cure for leaky fuel taps?
My problem is that they also seem to be "awkardly tight" to turn on and off.
The main problem seems to be internally... with the brass conical barrel which is non- sealed.
I am thinking that this item needs to be finely lapped together ( perhaps with a very fine metal polish) as to mate with the internal body, to create a leak proof seal????

I think these fuel taps are non genuine!

Thanks,

Brewer.

Joined
Jan 10, 2005
Messages
1,043
Country flag
If you don't mind non originality get hold of the BAP taps as used on late model classic Trumpets. They don't leak, are not expensive and flow plenty of fuel.

Joined
Nov 18, 2005
Messages
922
Country flag
You can lap them in and sometimes it works.

Most taps have a circlip that holds them together. Just pop that off and they fall apart. I lap them in with a metal polish paste called Solvol.

Joined
Oct 1, 2007
Messages
122
Ok! thanks guys. I will lap them in again and hope that stops the "annoying" fuel leaks.........
If not , I will look into buying the Triumph items.

Brewer.


batrider

VIP MEMBER
Joined
Aug 9, 2008
Messages
2,301
Country flag
I have several pairs of the repro metal shaft fuel taps that I got for about $25-30 a pair on ebay. I remove the snap ring and lube the seal with silicone grease (available from NAPA) every year. No problems.

The BAP petcocks are big and ugly and also will develop the same "annoying" sticking problem. (So annoying that they flew across the garage right into the trash. That was very satisfying. :twisted: )

Joined
Jan 27, 2008
Messages
1,607
Country flag
The taps that came with my bike seem original, and the petcock portion seems to be some sort of whitish plastic, harder than nylon, maybe a phenolic resin. I cleaned them really well, but they started weeping. I got the Emgo copies with the rubber sleeve seal that fits between the petcock and the housing, but they don't flow worth a darn, and the ethanol started swelling the rubber within a month. Put the originals back on after another careful cleaning, and no more problems, knock wood.

Joined
Aug 8, 2005
Messages
2,427
Country flag
http://www.britishbikeconnection.com/
Go to custom parts...scroll down.... Leak Proof Petcocks
These are the best on the market that I have found. Comes with all the seal washers and nuts. Choose Reserve and Main.
Not original looking but a very good mod. Fits your Original thread in your Commando tank. Cheers
CNN

Joined
Aug 14, 2006
Messages
1,451
Country flag
CanukNortonNut said:
http://www.britishbikeconnection.com/
Go to custom parts...scroll down.... Leak Proof Petcocks
These are the best on the market that I have found. Comes with all the seal washers and nuts. Choose Reserve and Main.
Not original looking but a very good mod. Fits your Original thread in your Commando tank. Cheers
CNN

I have two sets of these and they are really nice.

Joined
Jun 14, 2007
Messages
1,740
Country flag
They ARE nice. Be aware that they don't play nice with Keihin FCR carbs - I destroyed one that way - they interfere with one another, and the FCRs actually killed the right-side petcock. Put a hole in it through touching/vibration.

Joined
May 7, 2005
Messages
6,129
Country flag
Never had a problem with BAP's, have them fitted to a B44 and a commando for over 20 years, other than the zinc plating tarnishing no issues.

Joined
Nov 10, 2006
Messages
1,433
Country flag
Make your own from a pair of 1/4 BSP ball valves male to female they start from £1.50p each and they come in anything from chrome plated or stainless steel. You'll also need two 1/4 to 1/4 male brass connectors into which you can solder the filter gauze and the main supply level tube taken from the useless standard cock.

They last for ever and never ever leak, mine are now 14 years old.

Cash

Joined
Apr 15, 2004
Messages
1,616
Country flag
+1 for BAPs. I have them on both of my Nortons and have had no problems with them. I use stat-o-seal washers instead of the fiber washers and have no leakage. I found the fiber washers didn't seal very well on my fiberglass tank.

The OEM-style petcocks that came on my 750 were leaking badly, so I first bought new Asian-made OEM replicas. They only lasted two weeks. The seals they used were not compatible with ethanol fuel.

Debby

Joined
May 19, 2006
Messages
1,612
Country flag
The original BAP taps were all metal. I have since seen them with plastic levers. The originals seem to go on for ever. 20 years plus. I don't find them big and ugly.

Leaky fuel taps


I also have late Triumph footrest rubbers (In my defence, I had a pair left over from a Benelli before I found out they were also a Triumph part).

Leaky fuel taps

Joined
Aug 21, 2006
Messages
748
Country flag
I second (or third, or fourth) the vote for BAP taps. I have them on several bikes and they don't leak. I also don't mind the look of them at all.

Joined
Oct 1, 2007
Messages
122
Hi 79x100.
Those "BAP" fuel taps look fine on your bike. And no leaks!!!!
I am now convinced to go out and and buy a pair for my 850 Commando.

Thanks very much "everybody".

Brewer.
