1975 Norton 850 Mark 3 Electric Start Roadster Decals

thackero

Joined

May 6, 2014

Messages

74

• Oct 8, 2014

• #1

Does anyone have any pictures of where all the original decals were located on the 75 model Norton's. I have pics of the tank and side panels its all the other smaller frame, oiltank, fender etc etc decals/stickers.



searunner

Joined

Jan 3, 2014

Messages

41

• Oct 9, 2014

• #2

https://picasaweb.google.com/1127708198 ... 06DP1tHsNg
Google Album with Few photos of frame decals for 1985 850 Mk3



O

olChris

Joined

Oct 6, 2013

Messages

865

• Oct 9, 2014

• #3

I have about 20 photos like below for tank and panels if you want them ... PM me with personal Email address if you want..



thackero

Joined

May 6, 2014

Messages

74

• Oct 9, 2014

• #4

Thanks guys that is a great start. My gas tank and side panels are sorted. The frame decals take care of two of the decals I have. There should a couple of silver Square E decal somewhere and also a few decals on the oil tank. Does anyone know where the gear change pattern decal was located. Was it on the top of the gas tank ?



O

olChris

Joined

Oct 6, 2013

Messages

865

• Oct 10, 2014

• #5

The only other decal i can remember on my MK3/75.. I have never seen a decal on the oil tank.. Others will know better..



P

Possum

Joined

Jan 4, 2012

Messages

48

• Jun 20, 2016

• #6

Chris

I realize it is an old post, but do you still have images / measurements of the decals on the roadster tank?

Cheers, Possum



R

Rohan

Joined

Aug 26, 2010

Messages

8,215

• Jun 22, 2016

• #7

Measurements would assume the pinstriping was all identical, which you can't always take for granted.

If you centralize the Norton logo between the top and bottom pinstripes,
and place it midway in the panel fore-and-aft, you can't go wrong.

AND, put it on with the tank fitted to the bike, so the decal isn't heading uphill or downhill.
Cheers.

http://i.ebayimg.com/00/s/MTIwMFgxNjAw/ ... i/$_57.JPG
