Re: Dynojet

Postby Raphi » Fri Apr 07, 2017 8:05 am

Do you mean something like this?
User avatar

Raphi
Posts: 182
Joined: Mon Aug 17, 2015 2:10 pm

Re: Dynojet

Postby BritTwit » Fri Apr 07, 2017 8:28 am

Raphi wrote:Do you mean something like this?


Yes.
For sure, tuned velocity stacks would provide better top end performance, but the pictured units would provide no air filtering protection for the motor.
I think either K&N or Uni Filter have pods that incorporate plastic velocity stacks inside the filter that would eliminate the airbox restriction and provide the benefits of a bellmouth intake to the throttle bodies.

Eliminating the airbox does create an unfortunate aesthetic issue, but a faux airbox ( 2 fiberglass side covers) could be fabricated to cover, and even channel air into the area.
1975 850 MKIII Commando
2013 961 Commando Cafe Racer
2006 Triumph Bonneville T100
2003 Ducati 999
User avatar

BritTwit
Posts: 779
Joined: Tue Aug 25, 2009 6:15 pm
Location: NYC

Re: Dynojet

Postby GKRyder » Fri Apr 07, 2017 5:13 pm

Where do you think are the rest of the electrics in the above bike.

Still in tail? Or just a 'display' bike.

Looks plenty cool though.

GKRyder
Posts: 94
Joined: Sat Mar 19, 2016 11:04 pm

Re: Dynojet

Postby Fast Eddie » Fri Apr 07, 2017 6:12 pm

Rojah wrote:Hi TonyA,

Thanks for your comments. I didn't want to post the actual graphs at this stage, as Dynojet have been so good with me, I thought that I would let them have the pleasure.

But the peak figures were as follows, bike has 8500 miles and "louder" peashooter pipes fitted.

Max power std 72.02hp @7050rpm Max torque std 57.4ft-lbs @6000rpm

Max power Dynojet 74.1hp @7230rpm Max torque Dynojet 58.44ft-lbs @5770rpm

Engine feels much happier to rev out to the limiter now especially in 3rd and 4th gears, but still gobs of torque lower down. Fun!

Regards

Rojah


With such small gains, does this suggest that the factory set up ain't so bad after all ?
User avatar
Access Norton VIP Paying Member
Fast Eddie
VIP MEMBER
Posts: 3477
Joined: Fri Oct 04, 2013 12:48 am
Location: Oxford, England

Re: Dynojet

Postby iwilson » Fri Apr 07, 2017 10:45 pm

No, my dyno runs show the fuelling is still not optimum, no doubt the timing is also set with a reasonable safety margin. Personally I think it has 'enough' for its market niche. I'd just like to see it cleaned up a bit more - it's a little frustrating seeing it run massively rich at some points without the means to do anything about it.
User avatar

iwilson
Posts: 114
Joined: Fri Nov 06, 2015 3:16 am
Location: New Zealand

Re: Dynojet

Postby Rojah » Sat Apr 08, 2017 12:04 pm

Good evening,

I would post the graphs I have, if it wasn't so ******ing difficult!

Anyway to put the record straight. Ever since I had the bike back in April 2011 it ran rich, and on occasion it smoked. It smelt of unburnt fuel, and riders would refuse to follow behind because of the smell. I only got about 45-48mpg (imperial) at best, whether gentle or hard riding. It has a great top end though, and once was quite happy at 130mph indicated for many miles on the autobahn....

The previous regime of service clowns and contacts (pre Karen, who incidentally was excellent) at the Norton Factory claimed it was remapped to fit the loud silencers, I suspect not done properly. After a long tour in Scotland I complained to Norton about the fuelling and one of the previous service managers suggested that the plugs were faulty, and said to try a new set! Pratt.

The Dynojet team told me the plot was running very rich indeed, Air fuel ratio of 12.0 average across the range, with the new Power Commander it is approx 13.8 to 14.0, according to my reading of the graphs, so I now feel vindicated.

Still, this is all part of the overall "experience" of owning an "enthusiasts" bike, well that's what some of my friends say.

If I can work out how to post the graphs, I will.

Thanks for your interest - and a brilliant forum by the way.

Regards

Rojah
2011 Norton Commando 961 Sport
2016 CCM GP450 S
1962 BSA Rocket Gold Star
1976 Suzuki GT500A
1972 Suzuki TS125J Duster x 2

Rojah
Posts: 5
Joined: Mon Apr 03, 2017 8:29 am
Location: Lancashire, UK

Re: Dynojet

Postby iwilson » Sat Apr 08, 2017 10:55 pm

TonyA wrote:Hello Iwilson , The numbers he had to start with are way above mine now. I am at 69HP/53 Torque . But an additional 2HP and 2 ft lbs on top of what I have will interest me.


Hi Tony, comparing the numbers from one dyno to another is pretty pointless (his engine could make less hp on your dyno), the before and after is all that matters. You'd be hard pressed to notice a 2hp peak difference. But you'd certainly notice a big difference if the mapping was cleaned up throughout the rev range. That's why I'm interested in seeing the before and after graph.

Rojah wrote:Good evening,

I would post the graphs I have, if it wasn't so ******ing difficult!".............

Rojah


Rojah, the easiest way is to open a free account with Photobucket. Upload the graph to photobucket. Click on the graph once uploaded and copy the direct link (you'll see it to the right of the photo in the share this photo options). Start a post here click on the Img button and paste the link. Job done. :D
User avatar

iwilson
Posts: 114
Joined: Fri Nov 06, 2015 3:16 am
Location: New Zealand

Re: Dynojet

Postby Rojah » Sun Apr 09, 2017 2:10 am

Here goes, I hope it works!

[URL=http://s1174.photobucket.com/user/rwbeard1/media/IMG_0172_zpsrvg33pzw.jpg.html]Image[/URL


2011 Norton Commando 961 Sport
2016 CCM GP450 S
1962 BSA Rocket Gold Star
1976 Suzuki GT500A
1972 Suzuki TS125J Duster x 2

Rojah
Posts: 5
Joined: Mon Apr 03, 2017 8:29 am
Location: Lancashire, UK

Re: Dynojet

Postby Fast Eddie » Sun Apr 09, 2017 3:49 am

I'm clearly thicker than average cos I don't understand the first graph! What's it showing exactly?

I understand the second graph. And I would suggest that the difference shown would be hard to detect. That DOES NOT mean it is not better to ride, the improved fueling will surely make itself felt, but the actual power and torque increases would require the arse of a Princess to detect !
User avatar
Access Norton VIP Paying Member
Fast Eddie
VIP MEMBER
Posts: 3477
Joined: Fri Oct 04, 2013 12:48 am
Location: Oxford, England

Re: Dynojet

Postby TonyA » Sun Apr 09, 2017 7:38 am

Hello , I am afraid this looks like DIN numbers. Is there any chance Dyno Jet can give you numbers in SAE ? I WILL take the 2 hp and the 2 ftlbs torque on top of what I have any day .. It looks like they have got your AFR just perfect across the rev range ! This engine should pull to the limiter in 5th gear. Mine will now , 18T fr sprocket.. What is the cost to get this done I wonder. ? But the fact is we cannot compare because If these are DIN values then this will be in the 69/70 on a SAE machine. Please get Dyno Jet to clarify convert DIN vs SAE. We use SAE here. Thank You again , and you have done a great service !

TonyA
Posts: 710
Joined: Fri Jan 16, 2015 10:14 am
Location: Milwaukee WI. USA
